Description
BANNER Information:
T18 SERIES SELF-CONTAINED BARREL-MOUNT SENSOR EZ-BEAM T18
EZ-BEAM T18 Series: Polarized Retro
Range: 2 m; Input: 10-30 V dc
Output: Complementary PN
Euro M12 4-pin Integral QD
Part Number: 33417
SPECIFICATIONS
Sensing Beam Visible Red LED
Power DC
Sensing Mode (General)Retroreflective
Sensing Mode (Detailed)Polarized
Housing Style Barrel
Primary Housing Material Thermoplastic
Input/Output Discrete
Max Sensing Distance (mm)2000
Outputs PNP
Power Supply/Supply Voltage10-30 V dc
Connection Integral QD
Quick Disconnect TypeM12 (Euro)
Min Op. Temp. (°C)-40
Operation Light/Dark Operate
Max Op. Temp. (°C)70
Output response time (ms)3
Special Feature: Intrinsically Safe No
Special Feature: Remote Teach No
Special Feature: Water Detection No
Delay at Power-up (ms)100
Repeatability (µs)750
Number of Pins4
IP RatingIP67, IP69
NEMA Rating NEMA 6P
Max Op. Relative Humidity [%]90% @ 50°C
Lens Material Acrylic
Adjustments N/A
Barrel Diameter (mm)18
Indicator LEDs
Opposed Mode Emitter/Receiver N/A
Feature: Washdown Rated Yes
Feature: Timing (Hold/Delay)No
Feature: Ecolab Certified Yes
Feature: Encapsulated Yes
Feature: Hazardous Area No
Feature: Audible No
Feature: Chemical Resistant Yes
Feature: Health/ Marginal Signal Output Yes
DeviceNet No
IO Link No
PEPPERL+FUCHS Information:
Reflector, round ø 25 mm, screw fixing M4
Ambient temperature -20 … 85 °C (-4 … 185 °F)
Mechanical specifications
Material: PMMA/ABS
Dimensions Diameter: 25 mm
Mounting: screw fixing
